Multi Substrate UV Flatbed Printer for Wood, Glass, Metal and Acrylic.
Speed and Accuracy
Capable of producing 6 square meters per hour, this machine features Epson I3200-U1 heads (3 or 4 optional). The platform includes intelligent zone suction that auto-detects material size for precise hold-down, while a visual positioning system ensures accurate alignment.
color configuration
Rich color options include CMYK, white, varnish, and frost—all printable in a single pass across 1200×1000mm. Driven by 3 or 4 Epson I3200-U1 heads, this UV flatbed printer also features zone suction and visual positioning for reliable production.
return on investment
Get more from your equipment with a UV flatbed printer that combines 3 or 4 Epson I3200-U1 heads, 1200×1000mm format, and CMYK plus white, varnish, and frost. Smart suction and visual positioning reduce waste while maintaining 6㎡/h production speeds.
Product Details
01 Transmission Beam Guide Rail
• Beam: All-steel structure ,5mm thick steel plate
• X-axis: Japan imported THK dual linear guide rail
• Ensures stable carriage movement during printing
02 Anti-Collision Device
• Anti-collision devices on both sides of the printhead
• Automatically stops the machine when obstacles are detected
• Effectively protects the printhead from damage
03 Imported UV Lamp
• Imported LED chips with long service life
• Tilted UV lamp design prevents light reflection onto the printhead
• Avoids fatal damage to the printhead
Technical Specifications
04 High-Toughness Cable Chain
• High-toughness cable chain reduces wire wear
• Extends cable service life
• Low noise during operation
Technical Specifications
| Printer Model |
KY1210 |
| Print Head |
Epson I3200 U1 Head |
| Print Format |
1200mm × 1000mm |
| Print Color |
CMYK+white+varnish+frosted |
| Ink Type |
Environmentally Friendly Water-Based Pigment Ink |
| Printing Height |
10-13CM |
| Speed |
8pass bidirectional 6 square meters per hour |
| Power Supply |
200V/4500W.50HZ/60HZ |
| Operating Enviroment |
Temperature:18-30°,Humidty:40%-60%,Dust-Ree Room |
